Active™ Hose Reel Wall Mount System

Active™ Hose Reel Wall Mount System

Regular price$379.99
/
Shipping calculated at checkout.
  • In stock, ready to ship
  • Backordered, shipping soon

The Active pressure washer hose reel wall mount solution is an all-in-one garage solution that keeps pressure washer setups organized, accessible, and clutter-free.

Not only is it suited for Active products program but can also be a suitable upgrade kit for all pressure washer users when it comes to enhancing their car wash experience.

FREE SHIPPING (Lower 48 United States)

Key Features:

  • Systemic car wash at home: The Active hose reel wall mount system enables you to have a decluttered setup all in one place, allowing you use and put away your pressure washer system with ease.
  • Organized hose and accessory management: A storage slot for all accessories from your nozzles, foam cannon, gun and lance. The included reel also accommodates up to 100’ for 3/8 and 5/16 hoses
  • Safe and easy to mount: The provided backing plate comes with 16” stud spacing and easy latch system which allows you to safely mount the solution to your garage whether on studs or concrete.
  • Compatible with many pressure washers and accessories: Since the accessory holders come with ¼” rubber grommet plugs, it has universal product storage capabilities. And for the pressure washer there is a slot system that should allow you to mount any solution for your garage.
  • Optimized for Active systems: Despite universal adaptability, the system is optimized for used with Active 2.0 and 2.3 pressure washing solution and the Active accessory solution.

What’s the max rating for the hose reel and wall mount solution?

  • The hose reel valves has a max rating of 3000 peak pressure, 2100 PSI operating pressure and 3.5 GPM max flow rate, within limit for most industrial automotive pressure washers.

What if I encounter leaks in the hose reel wall mount solution?

  • The hose reel is completely rebuildable. Active carries all parts from O-rings to valves which can be replaced once worn out.

What is included in the hose reel wall mount solution?

  • The hose reel wall mount solution comes with a backing plate with 16” stud spacings, the main frame with hose reel for 100’ hose. And a jumper hose to connect to pressure washer.

What pressure washers can be mounted on the hose reel wall mount solution?

  • Most automotive pressure washers can be mounted on the plate with a max weight rating of 88lbs for the pressure washer.

User Manual

Hose reel

  • Inlet fitting: 3/8” QC female coupler
  • Outlet fitting: M22x1.5-14
  • Extension hose pre-installed
  • Reel rotation lock: release lock pin before turning the reel
  • Hand crank: customer need install hand crank and lock by pin
  • Hose clamp: customer needs to make adjustment to secure hose
  • Stainless steel (304) reel valve

Metal frame

  • Hose reel is pre-installed on frame
  • Customer installation is required for wall mount mode
  • Customer installation required for gun holder and fasten by screw
  • Customer adjustment is required for hose clip

Tip rest seat

  • 4 pcs rubber grommets pre-attached on rear wall

Foam cannon rest seat

  • 1pc rubber grommet pre-attached on mounting bracket

Wand rest seat

  • 1pc rubber grommet pre-attached on mounting bracket

Extension hose

  • 5/16” rubber hose, 340mm in length
  • M22x1.5-14 connector for pressure washer
  • Female fitting for jumper hose male fitting (SST304)

Hardware

  • 4pcs 6x30 mm screws to fasten mounting plate on the wall
  • 4pcs M8x 20mm bolts to secure wall mount to mounting plate
  • 2pcs M5x14 bolt to secure gun holder on frame

Accessories

  • Hand crank with lock pin
  • Mounting plate
  • Gun holder
  • Hardware kit

The Active hose reel wall mount solution comes with a 2-year end user warranty
